This is a continuation of the previous posts regarding how to trace an individual session as discussed in the below link
Oracle Application/session tracing methods - 1
and the methods of how to trace the sessions at application or database level as discussed in the below link
Oracle Application/session tracing methods - 2
You might see when we start tracing at application level, we get a bunch of trace files as there are multiple session involved. For eg., when we trace using a module, multiple sessions can run queries involving same module. In such cases, we can't go dig each and every trace file to investigate the issue. It would be much easier if we have a single consolidated trace file so that we can have a better understand of the issue we are investigating. Also, the trace file needs to be in human readable format rather some bunch of random random numbers here and there which only the computer can understand.
In this post we are going to look at how to consolidate multiple trace files as well how to make these trace files human readable using the below tools
- trcsess
- tkprof
trcsess
We can use the trcsess to consolidate trace files based on several criteria such as
- Session id
- Client id
- Service name
- Action name
- Module name
Let's see how to use this tool with an example. In my previous post, when I mentioned about tracing session with service name, I used Swingbench to generate load using 4 session. The session traces are as below
.. .. -rw-r-----. 1 oracle oinstall 4954796 Dec 15 00:25 orcl_ora_19415.trm -rw-r-----. 1 oracle oinstall 44587093 Dec 15 00:25 orcl_ora_19415.trc -rw-r-----. 1 oracle oinstall 4233304 Dec 15 00:25 orcl_ora_19413.trm -rw-r-----. 1 oracle oinstall 37791460 Dec 15 00:25 orcl_ora_19413.trc -rw-r-----. 1 oracle oinstall 4911273 Dec 15 00:25 orcl_ora_19411.trm -rw-r-----. 1 oracle oinstall 44277819 Dec 15 00:25 orcl_ora_19411.trc -rw-r-----. 1 oracle oinstall 3892558 Dec 15 00:25 orcl_ora_19409.trm -rw-r-----. 1 oracle oinstall 34574211 Dec 15 00:25 orcl_ora_19409.trc .. ..These 4 traces can be consolidated into a single trace file as below
Syntax: trcsess [output=] [session=] [clientid=] [service=] [action=] [module=]
[oracle@linux75-2 trace]$ [oracle@linux75-2 trace]$ trcsess output=service_orcl_trace.trc service=ORCL orcl_ora_19415.trc orcl_ora_19413.trc orcl_ora_19411.trc orcl_ora_19409.trc [oracle@linux75-2 trace]$ [oracle@linux75-2 trace]$ ls -lrt service_orcl_trace.trc -rw-r--r--. 1 oracle oinstall 161234967 Dec 19 23:56 service_orcl_trace.trc [oracle@linux75-2 trace]$ head -20 service_orcl_trace.trc *** [ Unix process pid: 19415 ] *** 2021-12-15T00:25:01.309981+05:30 *** [ Unix process pid: 19413 ] *** 2021-12-15T00:25:01.309867+05:30 *** [ Unix process pid: 19409 ] *** 2021-12-15T00:25:01.309928+05:30 *** [ Unix process pid: 19415 ] *** 2021-12-15T00:25:01.309986+05:30 *** [ Unix process pid: 19413 ] *** 2021-12-15T00:25:01.309871+05:30 *** [ Unix process pid: 19409 ] *** 2021-12-15T00:25:01.309933+05:30 *** [ Unix process pid: 19415 ] *** 2021-12-15T00:25:01.309990+05:30 *** CLIENT DRIVER:() 2021-12-15T00:25:01.309999+05:30 WAIT #0: nam='SQL*Net message to client' ela= 1 driver id=1413697536 #bytes=1 p3=0 obj#=-1 tim=11623002622 WAIT #0: nam='SQL*Net message from client' ela= 111757 driver id=1413697536 #bytes=1 p3=0 obj#=-1 tim=11623121966 WAIT #0: nam='latch: shared pool' ela= 230 address=1613615352 number=551 why=1787423120 obj#=-1 tim=11623122364 WAIT #0: nam='library cache load lock' ela= 13162 object address=1757868440 lock address=1759806192 100*mask+namespace=5177347 obj#=-1 tim=11623135636 [oracle@linux75-2 trace]$You can notice that I'm providing the trace files for the trcsess to look into for trace details, otherwise trcsess will look into all the trace files inside the trace directory.
Also, once the trace files are consolidated, the trace file shows the pid of all the sessions traced in the beginning.
tkprof
The raw trace file as I mentioned in the beginning of this post is in Oracle proprietary format like below.
.. .. *** 2021-12-15T00:25:01.309990+05:30 *** CLIENT DRIVER:() 2021-12-15T00:25:01.309999+05:30 WAIT #0: nam='SQL*Net message to client' ela= 1 driver id=1413697536 #bytes=1 p3=0 obj#=-1 tim=11623002622 WAIT #0: nam='SQL*Net message from client' ela= 111757 driver id=1413697536 #bytes=1 p3=0 obj#=-1 tim=11623121966 WAIT #0: nam='latch: shared pool' ela= 230 address=1613615352 number=551 why=1787423120 obj#=-1 tim=11623122364 WAIT #0: nam='library cache load lock' ela= 13162 object address=1757868440 lock address=1759806192 100*mask+namespace=5177347 obj#=-1 tim=11623135636 WAIT #139804731097848: nam='cursor: pin S wait on X' ela= 2567 idn=3873422482 value=1735166787584 where=21474836480 obj#=-1 tim=11623138951 ===================== PARSING IN CURSOR #139804731097848 len=82 dep=1 uid=0 oct=3 lid=0 tim=11623139023 hv=3873422482 ad='71383950' sqlid='0k8522rmdzg4k' select privilege# from sysauth$ where (grantee#=:1 or grantee#=1) and privilege#>0 END OF STMT PARSE #139804731097848:c=379,e=3165,p=0,cr=0,cu=0,mis=0,r=0,dep=1,og=4,plh=2057665657,tim=11623139020 EXEC #139804731097848:c=161,e=161,p=0,cr=0,cu=0,mis=0,r=0,dep=1,og=4,plh=2057665657,tim=11623139260 FETCH #139804731097848:c=74,e=74,p=0,cr=4,cu=0,mis=0,r=1,dep=1,og=4,plh=2057665657,tim=11623139366 WAIT #139804731068608: nam='cursor: pin S wait on X' ela= 3282 idn=3008674554 value=1735166787584 where=21474836480 obj#=-1 tim=11623142719 ===================== PARSING IN CURSOR #139804731068608 len=226 dep=1 uid=0 oct=3 lid=0 tim=11623142772 hv=3008674554 ad='71378ba8' sqlid='5dqz0hqtp9fru' select /*+ connect_by_filtering index(sysauth$ i_sysauth1) */ privilege#, bitand(nvl(option$, 0), 72), grantee#, level from sysauth$ connect by grantee#=prior privilege# and privilege#>0 start with grantee#=:1 and privilege#>0 END OF STMT PARSE #139804731068608:c=169,e=3381,p=0,cr=0,cu=0,mis=0,r=0,dep=1,og=4,plh=1227530427,tim=11623142771 WAIT #139804731068608: nam='PGA memory operation' ela= 8 p1=131072 p2=2 p3=0 obj#=-1 tim=11623142861 EXEC #139804731068608:c=118,e=118,p=0,cr=0,cu=0,mis=0,r=0,dep=1,og=4,plh=1227530427,tim=11623142960 WAIT #139804731068608: nam='PGA memory operation' ela= 7 p1=65536 p2=1 p3=0 obj#=-1 tim=11623143087 FETCH #139804731068608:c=209,e=209,p=0,cr=5,cu=0,mis=0,r=1,dep=1,og=4,plh=1227530427,tim=11623143182 FETCH #139804731068608:c=5,e=5,p=0,cr=0,cu=0,mis=0,r=0,dep=1,og=4,plh=1227530427,tim=11623143213 STAT #139804731068608 id=1 cnt=1 pid=0 pos=1 obj=0 op='CONNECT BY WITH FILTERING (cr=5 pr=0 pw=0 str=1 time=215 us)' STAT #139804731068608 id=2 cnt=1 pid=1 pos=1 obj=144 op='TABLE ACCESS BY INDEX ROWID BATCHED SYSAUTH$ (cr=3 pr=0 pw=0 str=1 time=29 us cost=3 size=20 card=2)' STAT #139804731068608 id=3 cnt=1 pid=2 pos=1 obj=147 op='INDEX RANGE SCAN I_SYSAUTH1 (cr=2 pr=0 pw=0 str=1 time=6 us cost=2 size=0 card=2)' STAT #139804731068608 id=4 cnt=0 pid=1 pos=2 obj=0 op='HASH JOIN (cr=2 pr=0 pw=0 str=1 time=125 us cost=7 size=115 card=5)' .. ..This is partially understandable but wouldn't it be nice to see the trace file in a more readable and easily understandable format?
For this we have tkprof (transient kernel profiler) provided by Oracle. tkprof accepts a trace file as input and produces a formatted output file and there a few options that we can make use of. Explain plan for the captured queries can also be made available as an option. Usage is as below
[oracle@linux75-2 trace]$ tkprof
Usage: tkprof tracefile outputfile [explain= ] [table= ]
[print= ] [insert= ] [sys= ] [sort= ]
table=schema.tablename Use 'schema.tablename' with 'explain=' option.
explain=user/password Connect to ORACLE and issue EXPLAIN PLAN.
print=integer List only the first 'integer' SQL statements.
pdbtrace=user/password Connect to ORACLE to retrieve SQL trace records.
aggregate=yes|no
insert=filename List SQL statements and data inside INSERT statements.
sys=no TKPROF does not list SQL statements run as user SYS.
record=filename Record non-recursive statements found in the trace file.
waits=yes|no Record summary for any wait events found in the trace file.
sort=option Set of zero or more of the following sort options:
prscnt number of times parse was called
prscpu cpu time parsing
prsela elapsed time parsing
prsdsk number of disk reads during parse
prsqry number of buffers for consistent read during parse
prscu number of buffers for current read during parse
prsmis number of misses in library cache during parse
execnt number of execute was called
execpu cpu time spent executing
exeela elapsed time executing
exedsk number of disk reads during execute
exeqry number of buffers for consistent read during execute
execu number of buffers for current read during execute
exerow number of rows processed during execute
exemis number of library cache misses during execute
fchcnt number of times fetch was called
fchcpu cpu time spent fetching
fchela elapsed time fetching
fchdsk number of disk reads during fetch
fchqry number of buffers for consistent read during fetch
fchcu number of buffers for current read during fetch
fchrow number of rows fetched
userid userid of user that parsed the cursor
[oracle@linux75-2 trace]$ tkprof service_orcl_trace.trc service_orcl_trace.out explain='sys as sysdba' table=sys.tkprof_table sys=no sort=exeela,execpu waits=yes
TKPROF: Release 12.2.0.1.0 - Development on Mon Dec 20 00:25:40 2021
Copyright (c) 1982, 2017, Oracle and/or its affiliates. All rights reserved.
password =
[oracle@linux75-2 trace]$
I have provided service_orcl_trace.trc file as input to tkprof to convert the file to service_orcl_trace.out file with explain plan for the queries along with their wait time statistics. I don't want to see the recursive calls made by sys and hence mentioned sys=no and would like to sort the output of the trace file with queries execute elapsed time and cpu time spent executing.
Sample output produced by tkprof will look like below
********************************************************************************
SQL ID: 982zxphp8ht6c Plan Hash: 1666523684
select product_id, product_name, product_description, category_id,
weight_class, supplier_id, product_status, list_price, min_price,
catalog_url
from
product_information where product_id = :1
call count cpu elapsed disk query current rows
------- ------ -------- ---------- ---------- ---------- ---------- ----------
Parse 95536 0.57 0.91 0 0 0 0
Execute 95536 1.00 1.58 0 0 0 0
Fetch 95536 0.80 1.32 28 286608 0 95536
------- ------ -------- ---------- ---------- ---------- ---------- ----------
total 286608 2.38 3.81 28 286608 0 95536
Misses in library cache during parse: 1
Misses in library cache during execute: 1
Optimizer mode: ALL_ROWS
Parsing user id: 89
Number of plan statistics captured: 6
Rows (1st) Rows (avg) Rows (max) Row Source Operation
---------- ---------- ---------- ---------------------------------------------------
1 1 1 TABLE ACCESS BY INDEX ROWID PRODUCT_INFORMATION (cr=3 pr=1 pw=0 time=543 us starts=1 cost=2 size=176 card=1)
1 1 1 INDEX UNIQUE SCAN PRODUCT_INFORMATION_PK (cr=2 pr=0 pw=0 time=244 us starts=1 cost=1 size=0 card=1)(object id 24503)
Elapsed times include waiting on following events:
Event waited on Times Max. Wait Total Waited
---------------------------------------- Waited ---------- ------------
SQL*Net message to client 95536 0.00 0.16
db file sequential read 28 0.00 0.02
SQL*Net message from client 95536 0.01 24.82
cursor: pin S 15 0.00 0.01
latch: cache buffers chains 1 0.00 0.00
********************************************************************************
The trace file now looks neat and easy to understand which can be interpreted and investigated for performance issues. A simple interpretation would be this specific select query has been run 95536 times with 28 blocks read for the disk or physical i/o and made 286608 logical i/o ti fetch 95536 records. This means the query is bringing 1 records per execution. Total elapsed time is 3.81 seconds with 2.38 seconds spent in cpu. The investigation can go for different queries to pin point the issues with the help of this tkprof trace file report.
So we conclude our tracing methods with this and I hope it is easy to follow and understand.
